| MODEL | [60hZ] | CS-PN9UKQ 1.0HP [CU-PN9UKQ] |
|---|
| Cooling Capacity | (min-max) | Kj/h | 9,000 |
|---|
| (min-max) | kW | 2.50 |
|---|
| EER | (min-max) | kj/hW | 10.7 |
|---|
| Electrical Data | Voltage | V | 230 |
|---|
| Running Current | A | 3.7 |
|---|
| Power Input | W | 860 |
|---|
| Moisture Removal | L/h | 1.5 |
|---|
| (Pt/h) | 3.2 |
|---|
| Air Circulation | m³/min. | 29.2 (1,030) |
|---|
| [Indoor/Hi] | ft³/min | 9.6 (339) |
|---|
| Noice Level | Indoor (Hi/Lo) | (dB-A) | 36/26 |
|---|
| Outside (Hi) | (dB-A) | 49 |
|---|
| Dimensions | Height | mm | 290 (511) |
|---|
| inch | 11-7/16 (20-1/8) |
|---|
| Width | mm | 799 (650) |
|---|
| inch | 31-15/32 (25-19/32) |
|---|
| Depth | mm | 197 (230) |
|---|
| inch | 7-3/4 (9-1/16) |
|---|
| Net Weight | kg | 8 (18) |
|---|
| Lb | 21 (46) |
|---|
| Refrigerant | Liquid Side | mm | ø 6.35 |
|---|
| Pipe Diameter | inch | 1/4 |
|---|
| Gas Side | mm | ø 9.52 |
|---|
| inch | 3/8 |
|---|
| Pipe Extension | Chargeless Pipe Length | m | 7.5 |
|---|
| Maximum Pipe Length | m | 20 |
|---|
| Maximum Elevation Length | m | 15 |
|---|
| Additional Refrigerant Gas* | g/m | 10 |
|---|
| Power Supply | Outdoor |
|---|
