FEATURES:
- 2 000 W motor with overload protection
- Stepless variable speed control with constant speed electronics
- Four speed gearbox with mechanical clutch
- MT3 spindle for a wide range of cutting tools and attachments to be directly mounted
- Unique through-the-spindle cutting fluid feed system
- Reversible motor rotation for tapping
- Special tang-drive arbors for both 31.75mm and 19.05mm shank cutters included
SPECIFICATIONS:
| Model |
MD120/4 |
|---|
| Power Input |
110-120V:1700W, 220-240V:2000W |
|---|
| Voltage |
110-120V~ 50-60Hz, 220-240V~ 50-60Hz |
|---|
| No/Full Load Min-1 |
Speed 1 |
35-120 |
|---|
| Speed 2 |
70-220 |
| Speed 3 |
80-250 |
| Speed 4 |
140-450 |
| Max. Capacity |
Dia. X Depth of Cut with 31.7mm (1-1/4") Weldon Shank Annular Cutter Arbor |
120mm x 50mm |
|---|
| Dia. X Depth of Cut with 19.05mm (3/4") Weldon Shank Annular Cutter Arbor |
120mm x 50mm |
| Dia. X Depth of Cut with Quick-Release Arbor |
60mm x 50mm |
| Dia. X Depth of MT3 Twist Drill Bit |
32mm x 200mm |
| Dia. X Depth of MT3 Chuck Adaptor With Twist Drill Bit |
16mm x 120mm |
| Dia. X Depth of Taps |
32mm x 40mm |
| Overload Protection |
With |
|---|
| Magnetic Adhesion |
32,000 N |
|---|
| Net Weight |
29.4kg(64.82Lbs) |
|---|
Standard Accessories: Wrench M8, Hex Key M2.5 & M5, Chip Guard Kit, Coolant Tank Kit,
Safety Chain, Drift, 31.75 Annular Cutter Set, Screw Arbor, 19.05 Annular Cutter Set Screw Arbor
