FEATURES:
- Magnetic Drill for medium size cutters
- 2 speed mechanical gearbox for added versatility
- Tool-free quick-release arbor for fast cutter changes
- Variable slide height allows quick conversion between cutters and twist drills
- Optional quick-release twist drill chuck adaptor fits directly into the arbor
SPECIFICATIONS:
| Model | SMD352 | SMD502 |
|---|
| Power Input | 1100W | 1100W |
|---|
| Voltage | 110-120V~ 50-60Hz,
220-240V~ 50-60Hz | 110-120V~ 50-60Hz,
220-240V~ 50-60Hz |
|---|
| No / Full Load Min-1 | Speed 1 | 450 / 270 | 300 / 180 |
|---|
| Speed 2 | 730 / 440 | 450 / 270 |
|---|
| Max. Capacity | Dia. X Depth Of Cut | 35mm x 50mm ( 1-3/8" x 2") | 50mm x 50mm (2" x 2") |
|---|
| Dia. X Depth Twist Drill Bit | 13mm x 140mm
(1/2" x 5-1/2") | 13mm x 140mm
(1/2" x 5-1/2") |
|---|
| Magnetic Adhesion | 17,000 N | 17,000 N |
|---|
| Net Weight | 16kg (33.07 Lbs) | 16kg (33.07 Lbs) |
|---|
Standard Accessories: Wrench M8, Hex.key M2.5 & M4, Coolant tank Kit, Safety Chain, Chip Guard Kit
